    1KV Digital Insulation Tester Full Button Easy Operation Ohm Meter

    Ask Lasest Price
    Brand Name : VICTOR
    Model Number : VC60B+
    Certification : CE
    Payment Terms : T/T PAYPAL
    Supply Ability : 10000PCS
    Delivery Time : 30-45 DAYS
    Price : USD23.5/pc
    • Product Details
    • Company Profile

    1KV Digital Insulation Tester Full Button Easy Operation Ohm Meter

    1KV Digital Insulation Tester Full Button Easy Operation Ohm Meter


    VC60B+ 1000V Insulation Tester New Professional Full Button Easy Operation Ohm Meter megometro Backlight smd earth tester megger


    GENERAL

    This instrument adopts the DC Voltage convertor of low consumption and high converter ratio inductance energy storage, to change the 9V Voltage to 250V/500V/1000V DC Voltage. It uses digital bridge to make the insulation resistance measurement had the features of user-friendly, high extent range, backlight display, data hold and auto power off. The whole instrument is stylish and superior grade in appearance and high stable in performance, it can be operated by both hands through using a shoulder strap. It is most suitable for the needs of insulation resistance check, such as electric, cable, electrical and mechanical equipment, telecommunication equipment and electrical facilities.


    Measured voltage250V±10%500V±10%1000V±10%
    RANGE0.1MΩ—20MΩ0.1MΩ—50MΩ0.1MΩ—100MΩ
    20MΩ—500MΩ50MΩ—1000MΩ100MΩ—2000MΩ
    Accuracy±(4% of reading ± 2 digits)
    Shot current1.8mA1.8mA1.6mA
    Median resistance2 MΩ2MΩ5MΩ
    Terminal position

    60B+ New Type Digital Insulation Tester

    Basic Function
    Measuring Voltage250V±10%500V±10%1000V±10%
    Range0.1MΩ~20 MΩ0.1MΩ~50 MΩ0.1MΩ~100 MΩ
    20MΩ~500 MΩ50MΩ~1000 MΩ100MΩ~2000 MΩ
    Accuracy±(4%+2)
    Current of Short Circuit1.8mA1.8mA1.6mA
    Median Resistance2MΩ2MΩ5MΩ
    Jack PositionL,E
    Special Function60B+
    Low Battery Indication
    Alarm FunctionRed indicator light is illuminated
    Over Load Indication
    Unit Symbol Display
    Auto Power Off
    Max. Display1999
    Using Temperature0℃~40℃
    Relative Humidity30%RH~85%RH
    Over Range Display“1”
    Dimension105×164×70mm
    Weight630g(including battery)
    Power9V(6个1.5V5# battery)
