Brand Name : | VICTOR |
Model Number : | VICTOR 5001 |
Certification : | CE |
Supply Ability : | 10000PCS |
Price : | USD13/pc |
Payment Terms : | T/T, Western Union, L/C, Paypal |
Delivery Time : | 5 to 30 days |
Relative Absolute Magnetic Digital Inclinometer 4*90° Magnets In Bottom Pocket Type
VICTOR 5001 Digital lnclinometer 4*90° Magnets in bottom pocket type
Mode 5001
Technical Parameters
1. Measuring range: 4*90°
2. Resolution: 0.05°
3. Accuracy: ±0.2°
4. Repeatability: 0.1°
5. Battery: AAA×2 battery
6. Working temperature: 0℃~40℃
7. Convenient to be attached to the object Measuring workpiece
8. Absolute zero measurement based on the level surface
9. Dimension: 57*57*30.5mm; N.Weight: 200g
Technical data | |
Model | 5001 |
Specification | |
Measuring range | 4* 90° |
Resolution | 0.05° |
Accuracy | +0.2° |
Repeatability | 0.1° |
Unit conversion | √ |
Data retention | √ |
Magnetic contact surface | bottom |
Working temperature | 0~40°C |
Automatic shut-down | 5min |
Zero setting | √ |
Standard test | √ |
Inclination test | √ |
Battery | AAA*2 battery |
Product size | 57 * 57 * 30.5mm |
Product weight | 200g |
General characteristics | |
●Aluminum alloy enclosure | |
●Relative/Absolute measurment interchange at any postion | |
●Absolute zero measurement based on the level surface |
![]() |
