Portable Multifunction Process Calibrator Rtd Calibration Equipment

VICTOR 24 Handheld Multifunction Process Calibrator 0.02% Accuracy Two Independent Channels For Input And Output 5 Digits Display

Introduction

This multifunction process calibrator (the calibrator in the following) is a handheld, battery-operated instrument that measures and sources electrical and physical parameters. (See Table 1)

Table 1 Source and Measurement Function

Except the functions listed in Table 1, the calibrator has the following features as well:

• You can operate the measurement and source function simultaneously. The LCD screen is divided into two separate districts, whose upper part displays measurement information and lower part displays source information.

• TC measurement/source terminals and built-in lead connector of same temperature (RJ compensation with auto-reference joint point)

• Manual step source and auto -step and sweeping –step source

• Room temperature monitoring under any operation

• Measurement/source temperature monitoring function

• Measurement/source mA% display

• Measurement wave-filter function

• Measurement manual-holding function

• Pressure source auto-holding function

• Contact Us

To purchase parts, obtain operation help or address of the vendor or service center nearest to you, please call us or visit our web (see the bottom page of the Manual).

• Standard Accessories

Make sure that the package contains all the accessories listed below. And if you find they are damaged or any of them is missing, please contact the vendor from which you purchased the product as soon as possible. Refer to the replacing part list in 15.3 in the Manual if you want to order the replacing parts.

• Two pair of Industrial testing Lead (H000002)

• A pair of Testing Probe (H000000)

• A pair of Alligator clip (H010000)

• A quick reference guide

• A User's Manual

• One Fuse 50mA/250V

• One Fuse 100mA/250V

Techincal Data
